ENGINEERING & PERFORMANCE CHARACTERISTICS

• Head diameter, height, bearing surface, and fillet radii manufactured to controlled tolerances.

• Concentricity between head, body, and threads supports stable seating and alignment.

• Unified and metric thread forms available in coarse and fine pitches.

• Flat or lightly chamfered point styles available to ease assembly.

  • Description
  • Features
  • Specifications

LOW HEAD SOCKET CAP SCREWS

Low head socket cap screws are designed for applications where standard socket head cap screws are too tall, yet reliable clamping strength, precision alignment, and repeatable performance are still required. With a reduced cylindrical head height, these fasteners enable secure assembly in shallow counterbores and space‑constrained designs without sacrificing structural integrity.

Low head socket cap screws are commonly used in compact machinery, tooling, automation systems, electronics housings, robotics, and precision mechanical assemblies where vertical clearance is limited.

COMMON APPLICATIONS

  • Compact machinery and automation equipment.
  • Tooling, fixtures, and precision alignment systems.
  • Electronics housings and enclosures.
  • Robotics and motion control assemblies.
  • Medical, aerospace, and instrumentation components.

DESIGN CONSIDERATIONS

Because of the reduced head height, wrench engagement is more limited than with standard socket head cap screws. Proper tool fit, controlled torque application, and correct material selection are essential. Low head designs are best suited for applications requiring moderate to high strength with restricted head clearance rather than maximum torque capacity.

WHY G‑FAST DISTRIBUTION

G‑Fast supplies low head socket cap screws using an engineering‑first approach that emphasizes dimensional accuracy, material integrity, and application‑appropriate performance. Through our Fasteneering® process, we review supplied prints for manufacturability, feasibility, and cost efficiency, ensuring every fastener meets your assembly requirements before production.
  • Reduced head height for tight vertical envelopes and shallow counterbores.
  • Cylindrical head geometry for predictable load distribution.
  • Available with internal hex socket or 6‑lobe internal drive configurations.
  • Designed for controlled torque application in manual or automated assembly.
  • Precision‑machined geometry supports repeatable torque‑to‑tension behavior.

AVAILABLE MATERIALS

Carbon & Alloy Steels

  • Heat‑treated alloy steel for high strength.
  • Black oxide, zinc, or phosphate finishes.

Stainless Steels

  • 300 Series Stainless (304, 316) for corrosion resistance.
  • 410 Hardened Stainless for higher strength stainless applications.

Specialty & Exotic Materials

  • Titanium – high strength‑to‑weight ratio and corrosion resistance.
  • Monel – excellent marine and chemical resistance.
  • Hastelloy – extreme temperature and chemical environments.
  • Additional engineered alloys available upon request.

INCH & METRIC AVAILABILITY

  • Inch and metric sizes available across common diameters.
  • Standard and custom lengths supported.
  • Modified head heights, drive styles, and made‑to‑print fasteners available through Fasteneering® review.
